10W-17W UV ballast 198-...
$15.00
Model No.︰
PD3-425-18
Brand Name︰OEM
Country of Origin︰USA
Added time:2013-11-08
Power factor: >0.5
Efficiency: >80%
Operating Frequency: 40-60KHz
Starting: Rapid
Dimensions: 65*45*35mm
Lamp status indication via LED indication
Green LED: lamp on
Red LED: lamp fault
Mounting Restrictions
Disconnect Input Power Before Installing or Servicing.
Don’t short any two wires of the four outputs.
For application with less than one switch-on cycle per day
(Otherwise preheat start ballasts are recommended)
Applications
All areas of applications include UV lamps.
Air purification
Aquarium
Domestic drinking water
Optional Parts
|
Type |
Input Voltage (V) |
Input Power (W) |
Input Current (A) |
Power Per Lamp (W) |
Lamp Current (A) |
Weight (kg) |
|
PD3-425-18 |
198-264 |
12-21 |
0.17A@230V |
10-17 |
0.35-0.42 |
0.15 |
